Blue Sea Systems 30 Amp Ac/Dc Magnetic Circuit Breaker 7238

• A-Series circuit breaker
• 30 amps AC/DC rating
• Double pole
• White toggle handle
• Combines switching and circuit protection into a single device
• Magnetic hydraulic trip-free design cannot be held ON during fault current condition
• The standard circuit breaker in Blue Sea Systems electrical panels
• 65 volts DC maximum voltage
• 250 volts AC maximum voltage
• #6-32 mounting screws included
• #10-32 terminal screws
• 0.630 in. diameter panel hole size for toggle switch
• 7500 amps interrupt capacity @ 65 volts DC
• 3000 amps interrupt capacity @ 120 volts AC
• 3000 amps interrupt capacity @ 120/240 volts AC
• 3000 amps interrupt capacity @ 250 volts AC
• Rated for 10,000 switching cycles @ rated amperage and voltage
• 1.50 in. width x 2 in. height x 1.64 in. depth
• Meets ABYC standards
• CE marked / TUV certified / CSA certified / UL 1077 recognized
• Replaces Ancor 552830
